AR-3201

Fast & accurate barcode scanner, Argox AR-3201 fulfills daily applications
Argox AR-3201 barcode scanner is designed for daily operations of small to medium-sized businesses. In their busy and intensive working environment, they need a reliable scanner to capture data with ease and without errors. AR-3201 speeds up customers’ checkout experience and gives increased efficiency.

---

1. Cordless and Lightweight design more converient & efficient to use
AR-3201 offers cordless with Bluetooth compatibility, freely and effiviently use everyday.

---

2. Long DoF Coverage
Covers from contact to standard scan range, one scanner that does the job of two (contact reading & distant reading).

---

3. Reads high density 3mil barcodes
Users can capture high density barcodes commonly used on small retail items such as jewelry.

---

4. Reads barcodes on LCD screens
Supports all types of electronic LCD screen, such as mobile phone, tablet.

---

5. Supports DataMagic function
Scanned data output can be customized to adopt various database structures.

---

6. Vibration function
With vibration mode, users can instantly confirm a successful scan even in a noisy environment.

---

Application

• Retail
• Manufacturing
• Healthcare

Light Source	RED LED 620nm~630nm
Image Sensor	2500 Pixel CCD
Depth of Field	Code39 3mil: 1.6cm~8.4cm Code39 4mil: 1.4cm~12.4cm Code39 5mil: 1.0cm~16.1cm Code39 20mil: 1.7cm~78.0cm EAN13 13mil: 1.3cm~53.5cm
Resolution	3mil (Code 39)
Print Contrast Ratio (minimum)	>30%
Decode Capability	Linear: Code11, Code39, Code93, Code32 (Pharmaceutical), Code128, Code bar, Interleaved 2 of 5, Industrial 2 of 5, IATA 2 of 5, Matrix 2 of 5, EAN/JAN-13, EAN/JAN-8, UPC-A, UPC-E, UPC-A/EAN-13 with EXtend Coupon code, Telepen, Plessey Code, GS1 Databar RSS14, GS1 Databar Limited, GS1 Databar, Omni directional, GS1 Databar Expanded, China Post Stacked Linear: GS1 Databar Expanded Stacked, GS1 Databar RSS14 Stacked, C16K, CodaBlockF
Wireless Communications	BT 2.1+EDR, 100meter Support SPP/HID
Communication Interface	USB(HID/Virtual COM), RS-232
Scan Indicators	LED, Beeper and Vibrator
Scanner Dimensions	H140mm x W67mm x D169mm
Cradle Dimensions	H106mm x W90mm x D141mm
Input Voltage	5V+/- 5%
Operating Temperature	-20°C to 60°C (-4°F to 140°F)
Storage	-20°C to 60°C (-4°F to 140°F)
Humidity	5% to 95% relative humidity, non-condensing
Ambient Light	Up to 80,000 Lux
Battery	Rechargeable Li-Ion batterypack (3.6V, 2600mAh, 9.36Wh) Full charged 5 hours (For adapter) Full charged 7 hours (For USB cable only) Standby idle >102 hours Number of scan >96,000 reads Expected hours of operation >81 hours
Drop Resistance	1.8M
Programming Method	User Manual setting barcode , Windows ScanUtility configuration program
Operation Mode	Trigger mode, Auto sensing mode
Sealing	N/A
Program Upgrade	Enabled by build-in flash memory
Cable Length	2.0m
Agency Listing	CE, FCC, BSMI, RoHS, WEEE, BIS
Weight	Scanner(battery included):178g Cradle:219g
Attention	*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.
