AS-8050 (Successor model: AS-8060)

product description
• Fast 1D barcode reading.
• Up to 3mil reading capacity.
• Easy to read screen barcodes.
  • New technology and powerful scan engine with excellent performance highly increase the reading speed. High density resolution that can capture the code on 3mil barcode such as jewelry tag. Support all type of electronic device, such as mobile phone, tablet and LCD display.
    Successor model: AS-8060
  •  Light Source 632nm visible red LED
     Image Sensor 2500 pixels CCD Linear Sensor
     Depth of Field 3mil Code39 30mm ~ 100mm, 5mil Code39 30mm ~ 150mm, 12mil Code39 35mm ~ 210mm, 13mil Code39 68mm~ 280mm, 13mil EAN13 48mm ~ 270mm, 34mil Code39 190mm ~ 700mm
     Resolution 3mil (Code39)
     Print Contrast Ratio (minimum) 25%
     Decode Capability 1-D Symbologies:EAN-8, EAN-13, UPC-A, UPC-E, CODABAR (NW7), Code 39, Code 93, INTERLEAVED 2 of 5, STANDARD 2 of 5, MATRIX 2 of 5, Code 128, EAN/UCC 128, Code 11, Chinese post
     Wireless Communications N/A
     Communication Interface USB HID, USB V-Com
     Scan Indicators LED, Beeper
     Scanner Dimensions 97mm x 67mm x 165mm
     Cradle Dimensions N/A
     Input Voltage 5V+/- 5%
     Operating Temperature -10˚C to 50˚C (14˚F to 122˚F)
     Storage -30˚C to 70˚C (-22˚F to 158˚F)
     Humidity 5% to 95% related humidity, non-condensing
     Ambient Light Up to 80,000 lux
     Battery N/A
     Drop Resistance 1.5m
     Programming Method Manual (reading special barcode)
     Operation Mode Trigger mode, Auto sensing mode
     Sealing IP42
     Program Upgrade Enabled by build-in flash memory
     Cable Length 1.8m
     Scanner Stand Standard
     Power Supply N/A
     Agency Listing CE, FCC, BSMI
     Attention *Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.
