AI-6800

product description
• Precision & Efficiency: Rapid reading speed at 700 scans per second. Three times the data transmission speed comparing to other scanners in its class.
• Excellent performance: Processing up to 3mil resolution barcode readability.
• Electronic Device Readable: Linear imager overcome the electronic scanning problem. Support all type of electronic device. such as mobile phone, tablet and LCD display.
• Ruggedized: Industrial grade IP65 dust and water resistance with 1.8 meters safe drop distance protection. It will withstand sudden drops and a variety of collision. AI-6800 will remain stable operation whether you use it for the outdoor or dusty environment.
Tags :
  • Scanner-3mil
  • Scanner-IP65
  • Scanner-Rugged
  • AI-6800 Series is the first rugged 1D linear scanner in Argox, with IP65 you can use it in severe environment like the Sahara desert or rain forests of Amazon with heavy humidity. Unlike the stand design and look of industrial barcode scanners, AI-6800 has more stylish and ergonomic design for function and aethetic.
    AI-6800 Series is compatible to standard 1D linear barcode, it also remove any reflection interference from the LCD display. The stand unit can be placed on the flat surface or to wall mounted. Under Presentation-mode can also reduced the inconvenience whileyou are inthe retail or packageing. AI-6800 Series has high density resolution that can capture the code on 3mil barcode such as electronic label. To achieve more efficiency you want, the scan process is only in 0.0012seconds.
    AI-6800 Series, with long DOF designed that is capable of capturing 1D barcode in long distance. That will besuitablefor retail, warehousing and logistic industry.
    The era of Big Data is coming, AI-6800 Series comes with DataMagic data editing software to enhance your usability. It takes no time to complete the setting with the user-friendly UI design; you will be able to complete the data analysis in no time. You no longer will need to spend additional resource on System Integrated companies for job like this!
  •  Light Source 630nm visible red LED
     Image Sensor 2500 pixel CCD
     Depth of Field Code39 3mil: 55mm~85mm, Code39 4mil: 55mm~115mm, Code39 5mil: 50mm~135mm, Code39 10mil: 35mm~310mm, Code39 13mil: 40mm~410mm, Code39 20mil: 45mm~565mm, EAN13 13mil: 40mm~355mm
     Resolution 3mil (Code 39)
     Print Contrast Ratio (minimum) 15%
     Decode Capability Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, EAN-8, Industrial 2/5, Interleved 2/5, Italian Pharmacode ( code 32), Matrix 2/5, MSI plessey, Standard 2 of 5, Telepen, UK plessey, UPCA, UPCE, China Post, Code-16K, RSS 14 (GS1 databar-14), RSS Expanded (GS1 DataBar Expanded), RSS Limited ( GS1 DataBar Limited)
     Wireless Communications N/A
     Communication Interface USB, RS-232
     Scan Indicators LED, Beeper and Vibrator
     Scanner Dimensions 94mm x 76mm x 158mm
     Cradle Dimensions N/A
     Input Voltage 5V+/- 5%
     Operating Temperature -20°C to 60°C (-4°F to 140°F)
     Storage -30°C to 70°C (-22°F to 158°F)
     Humidity 5% to 95% relative humidity, non-condensing
     Ambient Light Up to 100,000 Lux
     Battery N/A
     Drop Resistance 1.8m
     Programming Method User Manual setting barcode , Windows ScanUtility configuration program
     Operation Mode Trigger mode, Auto sensing mode
     Sealing IP65
     Program Upgrade Enabled by build-in flash memory
     Cable Length 2.0m
     Scanner Stand Optional
     Power Supply Optional
     Agency Listing CE, FCC, ROHS, BSMI
     Attention *Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.


  •
