AP-9800

product description

• 2,100 times/sec flying scanning speed.
• Exclusive anti-reflection technology.
• Easy to scan the mobile phone screen.

The omnidirectional reading 2,100 scans per second provides the market’s fastest decoding rate and motion tolerance.With exclusive technology, it can remove any reflection interference from the LCD display. Support all type of electronic device, such as mobile phone, tablet and LCD display.

Light Source	High Brightness White LED
Image Sensor	CMOS Sensor
Depth of Field	3milCode39 90mm ~ 110mm, 4.3mil DM 90mm ~ 125mm, 5mil DM 90mm ~ 135mm, 6mil DM 78mm ~ 135mm, 7mil Code39 50mm ~ 190mm, 10mil DM 38mm ~ 195mm, 20mil DM 38mm ~ 270mm,
Resolution	4mil (Code 39)
Print Contrast Ratio (minimum)	20%
Decode Capability	1-D Symbologies: EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 28, EAN-128, Codebar, industrial 2 of 5, Interleave 2 of 5, Industrial 2 of 5, MSI, postal codeEAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 28, EAN-128, Codebar, industrial 2 of 5, Interleave 2 of 5, Industrial 2 of 5, MSI, postal code. 2-D Symbologies: PDF417, MICRO PDF417, Datamatrix, QR, Maxicode, Aztec Code
Wireless Communications	N/A
Communication Interface	USB
Scan Indicators	LED, Beeper
Scanner Dimensions	140mm x 120mm x 170mm
Cradle Dimensions	N/A
Input Voltage	5V+/- 5%
Operating Temperature	0˚C to 55˚C (32˚F to 131˚F)
Storage	-20˚C to 60˚C (-4˚F to 140˚F)
Humidity	5% to 95% related humidity, non-condensing
Ambient Light	Up to 100,000 lux
Battery	N/A
Drop Resistance	2.0m
Programming Method	Manual (reading special barcode)
Operation Mode	Trigger mode, Auto sensing mode
Sealing	IP54
Program Upgrade	Enabled by build-in flash memory
Cable Length	2.0m
Scanner Stand	N/A
Power Supply	N/A
Agency Listing	CE, FCC, BSMI
Attention	*Argox reserves the right to enhance and modify the specification without prior notice. Please check Argox sales representative for most updated specifications.
