• 640 x 480 矩陣影像感測器
• 解析度:1D>=3mil(code 39); 2D>=7.5mil(QR)
• 可讀取UDI編碼的GS1 DataMatrix條碼
• 掃瞄範圍:60~200mm (Code 128, 10mil); 40~120mm (QR code, 10mil); 50~140mm (DM code, 15mil)
• 耐摔高度:1.5公尺落摔防護
• 具有自動感應模式
  • AS-9400-01

    1. 640 x 480 矩陣影像感測器

     2. 解析度: 1D>=3mil(code 39_; 2D>= 7.5 mil (OR)

    3. 可讀取UDI編碼的GS1 DataMatrix條碼

    4. 掃瞄範圍:
        60~200mm (Code 128, 10mil)
        40~120mm (QR code, 10mil)
        50~140mm (DM code, 15mil)

    5. 耐摔高度: 1.5公尺落摔防護

    6. 具有自動感應模式


    1. 零售業
    2. 製造業
    3. 貨運物流業
    4. 圖書館與辦公室
    5. 醫療業

  •  發光元件 630nm 可見紅光 LED
     掃描器種類 640 x 480 矩陣影像感測器
     景深 Code 128 10mil 18bytes: 60~200mm
    QR 10mil 160bytes: 40~120mm
    DM 15mil 100bytes: 50~140mm
     解析度 1D>=3mil (Code 39) 2D>=7,.5mil (QR code)
     Print Contrast Ratio (minimum) ≧25%
     解碼種類 1-D:
    Code11, Code39, Code93, Code32 (Pharmaceutical), Code128 (GS1-128), ISBT-128, Codabar (NW7), Interleaved 2of 5, Industrial 2 of 5, Discrete 2 of 5 (DTF), IATA 2 of 5, Matrix 2of 5, EAN/JAN-13, plus supplement, EAN/JAN-8, plus supplement, UPCA, plus supplement, UPCE, plus supplement, UPCE1, ISBN (Bookland), MSI Plessey Code, GS1 Databar RSS14, GS1 Databar Limited, GS1 Databar Omnidirectional, GS1 Databar Expanded
    GS1 Databar Expanded Stacked, GS1 Databar RSS14 Stacked, PDF417, Micro PDF417, Composite Codes (CC-A, CC-B, CC-C/CC-B, CC-C), Aztec, MaxiCode, DataMatrix/ECC 200, QR Code, Micro QR Code, GS1 DataMatrix
     無線通信 N/A
     通信介面 USB-HID, USB-Virtual COM
     讀取指示 LED, 蜂鳴器
     條碼掃描器尺寸 90mm x 60mm x 160mm
     充電座尺寸 N/A
     輸入電壓 5V±5%
     操作溫度 0°C to 50°C
     存放溫度 -20°C to 80°C
     存放溼度 5% to 95% 相對溼度 (非冷凝)
     抗光強度 最高100,000 lux
     電池 N/A
     耐摔測試 1.5公尺落摔防護(水泥地)
     編程方法 標準: 使用手冊設置條碼
     操作模式 觸發模式, 自感應模式
     防水防塵係數 IP41
     程式升級 可使用Flash記憶體作遠端升級
     傳輸線長度 1.8m
     條碼掃描器支架 選配
     電源 N/A
     安規認證 CE, FCC, BSMI, RoHS, etc.
     注意事項 * 立象科技保留增加和修改規格的權利,恕不另行通知。 請聯絡立象科技業務代表以獲取最新規格。
